1216C-SL005 by alpha wire
Image is representational - see mfr. specs

1216C-SL005

Alpha Wire

Multi-Conductor Cable Tape Polyvinyl Chloride 6 Conductors 24AWG 5.41mm 300VAC - Slate - 30.48m (100ft)/Spool ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 1216C-SL005 is a six-conductor shielded cable assembly designed for control and signal transmission in industrial and commercial applications. It features six 24 AWG tinned copper conductors with 0.010" PVC insulation, cabled together with a minimum twist rate of 6.0 twists per foot and protected by an aluminum/mylar tape shield with 25% overlap and a 24 AWG tinned copper drain wire. The cable is rated for 300V RMS operation over a temperature range of -20°C to +80°C, with a jacket wall thickness of 0.032" nominal PVC in slate color. Key electrical characteristics include a conductor DC resistance of 26 O/1000 ft at 20°C, capacitance of 45 pF/ft, and inductance of 0.19 µH/ft. This cable is ideal for applications requiring reliable shielded multi-conductor transmission with EMI protection and is RoHS 2 and CSA compliant.

Search Keywords: 1216CSL005

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Alpha Wire
部件编号:
1216C-SL005
Alias/AKA:
1216C-SLATE-100
计量单位:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Conductors:
6
Conductor Material:
Tinned Copper
Cable Length:
30.48 m
Maximum Current Rating:
N/A
Type:
Multi-Conductor Cable

有存货: 3

可立即发货

工厂库存: 90   可以发货 6/29/26

工厂交货期 10 周 可以发货 8/25/26

PRICE (USD)

数量
Unit Price
1
$318.30
3
$305.10
5
$296.39
10
$288.81
20 +
$273.20
Log in for special pricing Click for Quote Price Match Request
