1178C-SL005
Alpha WireMulti-Conductor Cable Polyvinyl Chloride 8 Conductors 22AWG 6.17mm 300VAC - Slate - Bulk - 30.48m (100ft)/Spool ...
描述
1178C-SL005 is an eight-conductor communication cable designed for general-purpose wiring and signal transmission applications. The cable features 22 AWG tinned copper conductors (7/30 stranding) with 0.010" nominal PVC insulation and a 0.032" nominal PVC jacket, providing robust electrical isolation and mechanical protection. The eight conductors are cabled together with a minimum twist rate of 4.8 twists per foot and are color-coded according to Alpha Wire Color Code D (black, red, white, green, orange, blue, brown, yellow). Electrically, the cable is rated for 300V RMS with a temperature range of -20°C to +80°C, a bend radius of 10× cable diameter, and a maximum pull tension of 44 lbs. The cable meets UL AWM/STYLE 2576 (80°C/150V RMS), UL CM (75°C), CSA CMG/FT4 (60°C), and EU Low Voltage Directive standards, making it suitable for control systems, instrumentation, and industrial automation where reliable multi-conductor connectivity is required.
Search Keywords: 1178CSL005
规格
有存货: 3
Ships today, if you order in
工厂库存: 52 可以发货 6/29/26
工厂交货期 9 周 可以发货 8/18/26
PRICE (USD)
Tools/3D Models
Shrink Tubing
产品说明书
