ABM8AIG-12.000MHZ-12-2Z-T3 by abracon
图片仅供参考 - 请查看制造商规格
Abracon 授权经销商

ABM8AIG-12.000MHZ-12-2Z-T3

SMD Crystal - 12.000MHZ ±20ppm - 12pF - -40°C to 125°C ...

查看数据表 询问数据表
符合 RoHS
REEL 包装
附件
请求编程报价
合规证书

描述

The ABM8AIG-12.000MHZ-12-2Z-T3 is an automotive and industrial-grade ceramic base SMD crystal designed for high-reliability applications. This device operates at a fundamental frequency of 12 MHz with a frequency stability of ±50 ppm over the operating temperature range of -40°C to +125°C, and features an equivalent series resistance (ESR) of 100 O typical. The crystal is housed in a hermetically sealed ceramic package measuring 3.2 × 2.5 × 0.8 mm, with a load capacitance of 18 pF and shunt capacitance of 2.0 pF, ensuring stable performance across automotive and industrial control applications. It is AEC-Q200 qualified, TS16949 production line certified, and RoHS/RoHS II compliant, making it suitable for infotainment systems, keyless entry, GPS/navigation, ADAS, vehicle-to-vehicle communication, and in-vehicle networking.

搜索关键词: ABM8AIG12000MHZ122ZT3

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Abracon
部件编号:
ABM8AIG-12.000MHZ-12-2Z-T3
计量单位:
每 Each
RoHS:
Yes
HTS:
8541600050
COO:
TW
ECCN:
EAR99
卷盘包装: 此信息适用于希望按制造商标准包装数量的倍数购买的客户。最低订购数量和要求的订购倍数会与价格和库存信息一同显示。
3000
封装类型:
REEL

常见问题

ABM8AIG-12.000MHZ-12-2Z-T3 是否符合 RoHS 标准？

是的，ABM8AIG-12.000MHZ-12-2Z-T3 符合 RoHS 标准。

ABM8AIG-12.000MHZ-12-2Z-T3 的交货期是多少？

ABM8AIG-12.000MHZ-12-2Z-T3 的标准交货期约为 14 周。有库存的数量由 Master Electronics 发货。

有存货: 3,000

可立即发货

最小订购数量: 500

工厂交货期 14 周

价格 (USD)

数量
单价
500
$0.819
1,000
$0.784
3,000
$0.729
6,000
$0.678
9,000
$0.658
12,000
$0.644
15,000
$0.633
27,000 +
$0.622
卷盘包装
登录以获取特别价格 点击询价 价格匹配请求

工具/3D模型

产品指南
