描述
AF116-30-00-13 is a 3-phase block contactor designed for motor starting, isolation, bypass, and distribution applications up to a maximum of 690 V. The contactor operates with a wide control voltage range of 100-250 V at 50/60 Hz and DC, providing flexible integration into various control systems. It features three main contacts (NO), a rated operational current of 160 A at 40°C in AC-1 duty and 116 A at 55°C in AC-3 duty at 380-440 V, with a rated breaking capacity of 8 × Ie and making capacity of 10 × Ie according to IEC 60947-4-1. The device has a mechanical durability of 5 million cycles and operates with a maximum electrical switching frequency of 300 cycles per hour for AC-1 and AC-3 duties. Its compact dimensions (150 mm height × 90 mm width × 126 mm depth) and double clamp terminal type make it suitable for industrial control panels and motor control centers where reliable switching and long service life are essential.
搜索关键词: AF116300013
规格
FREQUENTLY ASKED QUESTIONS
Is AF116-30-00-13 RoHS compliant?
No, AF116-30-00-13 is not RoHS compliant.
What is the lead time for AF116-30-00-13?
The standard lead time for AF116-30-00-13 is approximately 6 days. In-stock quantities ship from Master Electronics.
有存货: 3
发货 today, 输入设置值。
工厂交货期 6 周
价格 (USD)
工具/3D模型
产品指南
数据表
