GPTBNH11

Switch Snap Action N.O./N.C. SPDT Plunger Screw 20A 250VAC 250VDC 1491.4VA 6.37N Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

GPTBNH11 is a general purpose snap action switch from the GP Series designed for reliable switching applications. It features a maximum operating force of 22.9 oz, release force minimum of 7.1 oz, pretravel distance of 0.028 in (0.70 mm), and an operating point range of 0.826/0.890 in (21.00/22.72 mm). The switch is rated at 20A 250VAC per UL508, with a dielectric strength of 1000 VAC at 50/60 Hz for 1 minute, insulation resistance of 100M ohms minimum at 500 VDC, and initial contact resistance of 15m ohms maximum. Constructed with a rugged phenolic case and cover, silver alloy contacts, and brass screw terminals, this switch is mechanically tested to over 20 million cycles. It is ideal for industrial control, machinery, and equipment applications requiring durable and precise snap action switching.

Product Highlights:

  • Ultra-small travel differential
  • Mechanical life tested to 1 million cycles
  • Current switching to 20 amps
  • Wide variety of actuators
  • Screw or solder terminals standard
  • Low operate forces available

Search Keywords: GPTBNH11

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
GPTBNH11
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
800
Package Type:
BOX
Mounting:
Panel Mount,Screw
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plunger
Contact Rating @ Voltage:
1491.4 A
Maximum Movement Differential:
0.2 mm
Operating Force:
6.37 N
Termination Style:
Screw
Dimension:
49.6 x 17.6 x 48.74 mm
Body Orientation:
Straight
IP Rating:
N/A
