E72-40AT by zf electronic systems
Image is representational - see mfr. specs

E72-40AT

ZF Electronic Systems

The E72-40AT is a sealed, subminiature snap-action switch with a button actuator and silver alloy contacts. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The E72-40AT is a sealed, subminiature snap-action switch from the E72 series, featuring a button actuator. It is rated for 10.1A at 125/250VAC under UL1054 and has a minimum electrical life of 6,000 operations. This switch operates with a maximum force of 300 grams, features a maximum movement differential of 0.004 inches, and is designed to function reliably across a temperature range of -40°C to +85°C. Built with a hi-temp thermoplastic case and a water-resistant hydrin boot, this moisture-resistant switch is ideal for applications requiring durability and environmental protection.

Product Highlights:

  • Moisture resistant
  • 3 contact arrangements
  • Long life coil spring mechanism
  • Choice of button or hinged actuator
  • 10-inch, 16 gauge leads attached
  • Custom wire and harness designs available upon request

Search Keywords: E7240AT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E72-40AT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
High Temperature Thermoplastic Nylon/Button
Contact Rating @ Voltage:
186.42@UL A
Maximum Movement Differential:
0.1 mm
Operating Force:
2.94 N
Termination Style:
Wire Lead
Dimension:
23.24 x 9.78 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,559

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 250

Factory Lead-Time 16 Weeks

Qty
Unit Price
5
$10.77
50
$10.55
100
$10.45
250
$10.41
500
$10.38
750
$10.36
1,000 +
$10.33
Log in for special pricing Click for Quote Price Match Request
