E13-00H by zf electronic systems

E13-00H

ZF Electronic Systems

Snap Action Switch - SPDT - Lever - 15A@125/250VAC 2A@48VDC - Quick Connect - Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp part E13-00H is a versatile and reliable snap action switch designed for a wide range of applications. With a single pole double throw (SPDT) configuration and a lever actuator, this switch provides precise control and crisp switching action.Rated for a maximum current of 15A at 125/250VAC and 2A at 48VDC, the E13-00H switch can handle high-power loads with ease. It features quick connect terminals, allowing for easy and efficient installation. The switch is also screw mountable, ensuring secure placement and optimal functionality.Whether used in industrial equipment, consumer electronics, or automotive applications, the ZF Electronics Corp E13-00H snap action switch offers reliable performance and durability. Its compact size and versatile design make it a popular choice for professionals and hobbyists alike. Choose the E13-00H for your switching needs and experience exceptional quality and reliability.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.

Search Keywords: E1300H

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E13-00H
Alias/AKA:
0E1300H0
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
672
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Thermoplastic Nylon/Lever
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
2.36 mm
Operating Force:
0.98 N
Termination Style:
Quick Connect
Dimension:
86.43 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 9,006

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 20 Weeks

Qty
Unit Price
5
$5.63
50
$4.13
100
$4.03
250
$3.96
672
$3.80
1,344
$3.72
2,688
$3.56
5,376 +
$3.46
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
