80.010.4005.0 by wieland electric
Image is representational - see mfr. specs

80.010.4005.0

Wieland Electric

Electrical Connections Appliance Terminals ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 80.010.4005.0 is a 12 V AC/DC relay module designed for industrial control and switching applications. It features a single changeover contact (SPDT) rated for 250 V AC / 300 V DC at 6 A maximum switching current, with a maximum switching capacity of 1500 VA / 48 W. The module operates with a nominal input current of approximately 14 mA and nominal input capacity of 0.35 W, with a holding current greater than 1.2 mA at 20 °C. It provides fast response with pickup/dropout delays of 8 ms / 10 ms, a chatter time of 2 ms, and supports a maximum switching frequency of 20 Hz. The relay module measures 6.2 mm overall width with dimensions of 6.2 × 89 × 70 mm and is available with screw or spring-clamp terminals. It is suitable for DIN rail mounting (TS35) with IP 20 protection, operates across 0 °C to +50 °C ambient temperature, and includes a green LED status display for operational indication.

Search Keywords: 8001040050

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wieland Electric
Part No:
80.010.4005.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10

IN STOCK: 9

Can Ship immediately

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
1
$29.98
5
$28.26
10
$28.19
30
$27.43
50
$26.69
100
$26.62
250 +
$26.19
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
