70.400.0340.0 by wieland electric
Image is representational - see manufacturer specifications
Wieland Electric Authorized Distributor

70.400.0340.0

Conn Rectangular F 3Signal/1Ground POS Screw ST Cable Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 70.400.0340.0 is an industrial multipole connector insert designed for three-phase power distribution applications with an additional ground contact. It features a rated current of 16 A and operates at 690/400 V according to IEC 61 984 standards, with UL/CSA approval at 600 V. The insert accommodates wire cross-sections from 0.5 to 2.5 mm² (20 to 12 AWG) with screw connection terminals and tin-plated contacts, providing a wire strip length of 7 mm for secure connections. The connector is suitable for industrial control systems, machinery interconnects, and power distribution panels where reliable three-phase connections are required, offering IP 55 degree of protection and compatibility with M 20 cable entry threads.

Search Keywords: 7040003400

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wieland Electric
Part No:
70.400.0340.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Rectangular
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
PL
Pitch:
N/A
Termination Method:
Screw
Number of Contacts:
3Signal/1Ground
Maximum Voltage Rating:
690 V
Maximum Current Rating:
16 A
Operating Temperature:
-40 to 110 °C

FREQUENTLY ASKED QUESTIONS

Is 70.400.0340.0 RoHS compliant?

Yes, 70.400.0340.0 is RoHS compliant.

What is the lead time for 70.400.0340.0?

The standard lead time for 70.400.0340.0 is approximately 3 days. In-stock quantities ship from Master Electronics.

IN STOCK: 5

Can Ship immediately

Buy all 5 in-stock or the regular minimum order quantity of 10

Stock lot only: 5

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
1
$10.978
10
$9.980
30
$9.670
50
$9.240
100
$8.970
250
$8.480
500
$8.250
1,000 +
$8.140
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
