1748220000 by weidmuller
Image is representational - see manufacturer specifications
Weidmuller Authorized Distributor

1748220000

Conn Terminal Block SKT 16 POS 3.5mm Crimp ST Cable Mount 10A Box ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

The WEIDMULLER part 1277920000 is a PCB plug-in connector designed for easy and reliable connection on circuit boards. It features a female plug with a pitch size of 3.50 mm and comes with 16 poles, offering ample connection options. The connector utilizes a PUSH IN spring connection system, ensuring quick and secure wire termination. With a maximum clamping range of 1.5 mm², it can accommodate various wire sizes. The connector comes in a convenient box packaging, providing adequate protection during transportation and storage.

Search Keywords: 1748220000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Weidmuller
Part No:
1748220000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
48
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Pitch:
3.5 mm
Number of Circuits:
8
Maximum Voltage Rating:
300 V
Maximum Current Rating:
10 A
Wire Size:
16-28 AWG
Operating Temperature:
-50 to 100 °C
Life Cycle:
Discontinued & Replaced

FREQUENTLY ASKED QUESTIONS

Is 1748220000 discontinued?

Yes, 1748220000 from Weidmuller is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

What replaces 1748220000?

The recommended replacement for 1748220000 is 1277920000 from Weidmuller, available from Master Electronics.

Is 1748220000 RoHS compliant?

Yes, 1748220000 is RoHS compliant.

What is the lead time for 1748220000?

The standard lead time for 1748220000 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 1

Can Ship immediately

Buy all 1 in-stock or the regular minimum order quantity of 5

Stock lot only: 1

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
1
$9.042
5
$8.220
48
$7.620
96
$7.510
144
$7.400
288
$7.290
528
$7.180
1,008 +
$7.070
Supplier's Standard Package
