0474560000 by weidmuller
Image is representational - see mfr. specs

0474560000

Weidmuller

WEIDMULLER 0474560000 Fused Terminal Block, 2 Ways, 28 AWG, 12 AWG, 4 mm, Screw, 10 A ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 0474560000 is a SAK series fuse terminal designed for circuit protection, featuring a pivoting holder for G-Si 5x20 cartridge fuses. It utilizes a screw connection that accommodates a wire clamping range from 0.13 mm² to 4 mm² (AWG 26-12). This terminal is rated for a voltage of 500V and a current of 6.3A, with a rated impulse withstand voltage of 6 kV. Constructed from PA 66 material with a UL 94 V-2 flammability rating, it operates reliably in temperatures from -50°C to 100°C. Designed for snap-on mounting on TS 32 or TS 35 rails, it is ideal for industrial control panels and distribution systems requiring integrated overcurrent protection.

Search Keywords: 0474560000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Weidmuller
Part No:
0474560000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85369095
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Fuse Block
Mounting:
T DIN Rail
Gender:
N/A
Termination Method:
Screw
Pitch:
N/R
Number of Circuits:
1
Maximum Voltage Rating:
500 V
Maximum Current Rating:
6.3 A
Wire Size:
12-26 AWG
Operating Temperature:
-50 to 100 °C

IN STOCK: 358

Can Ship immediately

Manufacturer Stock: 1,600   can ship 5/4/26

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks can ship 6/24/26

Qty
Unit Price
5
$10.59
25
$8.95
50
$8.19
100
$7.09
300
$6.61
500
$6.47
1,000 +
$6.45
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
