970-FBW-DS/09 by weco electrical connectors inc.

Image is representational - see mfr. specs

970-FBW-DS/09

The 970-FBW-DS/09 is a 9-pole plug connector with a 5 mm pitch, featuring a screw connection that is pluggable from the bottom. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 970-FBW-DS/09 is a 9-pole pluggable screw terminal connector designed for bottom-entry wire connections. It features a 5 mm pitch and includes a wire protector to accommodate wire sizes from 18 to 12 AWG (0.75 - 2.5 mm²). The connector is rated for 250V (Overvoltage Category III) and 6A, with a rated impulse voltage of 4 kV. Constructed from grey, V-0 rated polyamide, it operates reliably over a temperature range of -40°C to 100°C. This component is ideal for industrial controls and automation systems requiring secure and serviceable wire-to-board connections.

Product Highlights:

Potential Applications:

Search Keywords: 970FBWDS09

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

WECO Electrical Connectors Inc.

Part No:

970-FBW-DS/09

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
