FD6-24 by triad magnetics
Image is representational - see mfr. specs

FD6-24

Triad Magnetics

The FD6-24 is a chassis-mount, Quick Pack power transformer with dual primary windings for 115V or 230V operation. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FD6-24 is a Quick Pack small power transformer designed to offer a significant reduction in size and weight over standard transformers. It has a maximum power rating of 30.0VA and supports dual input voltages of 115VAC (parallel) or 230VAC (series) at 50/60Hz. The transformer provides a center-tapped secondary output of 24.0V at 1.25A. Constructed with a split bobbin non-concentric winding, it eliminates the need for costly electrostatic shielding and features a UL Class B Insulation System. With terminations suitable for quick connects or soldering, this compact transformer is ideal for a wide variety of applications requiring a small operating space.

Search Keywords: FD624

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Triad Magnetics
Part No:
FD6-24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
PH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Primary Configuration:
Dual
Primary Side Voltage:
230,115 V
Secondary Configuration:
Single
Secondary Side Voltage:
24 V
Secondary Side Current:
1250 mA
Power Rating:
30 VA
Mounting:
Flange Mount
Dimension:
82.6 x 49.2 mm

IN STOCK: 64

Can Ship immediately

Manufacturer Stock: 134   can ship 5/4/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks can ship 8/26/26

Qty
Unit Price
5
$20.58
25
$15.65
50
$15.07
100
$13.84
250
$13.54
500
$13.12
1,000 +
$13.05
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
