RG9731

Name: RG9731 Thomas Betts Ring Lug
Brand: Thomas Betts
SKU: 12674069
Availability: InStock

Sta-Con® Nylon-Insulated Large Ring Terminal - Aircraft Wire Size 2AN - Material Copper - Tin-Plated Finish - Color Red - Bolt Hole 3/8 Inch - Voltage Rated 600V ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The RG9731 is a large ring terminal insulated with high dielectric-strength nylon for aircraft wire size 2AN. These ring terminals have funneled barrel entry, deep internal serrations, and overlapping seams. Length 2.07 inches, .69 inches width, maximum insulation .453 inches, bolt hole 3/8 inches. The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation, rated for 105°C max temperature. Installing tool TBM6S.

Product Highlights:

Potential Applications:

Search Keywords: RG9731

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Thomas & Betts

Part No:

RG9731

Alias/AKA:

MS-25036-127

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
