Image is representational - see mfr. specs

RG9711

Sta-Con® Nylon-Insulated Large Ring Terminal - Aircraft Wire Size 2AN - Material Copper - Tin-Plated Finish - Color Red - Bolt Hole 1/4 Inch - Voltage Rated 600V ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The RG9711 is a large ring terminal insulated with high dielectric-strength nylon for aircraft wire size 2AN. These ring terminals have funneled barrel entry, deep internal serrations, and overlapping seams. Length 2.07 inches, .69 inches width, maximum insulation .453 inches, bolt hole 1/4 inches. The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation, rated for 105°C max temperature. Installing tool TBM6S.

Product Highlights:

Potential Applications:

Search Keywords: RG9711

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Thomas & Betts

Part No:

RG9711

Alias/AKA:

MS-25036-126

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

3926904510

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
