Image is representational - see mfr. specs

RC10-250F

Sta-Con® Nylon Insulated Female Disconnect 250 Series - Wire Range #12-#10AWG - Material Copper - Tin-Plated Finish - Color Yellow ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The RC10-250F is a nylon-insulated female disconnect for wire range #12 - #10 AWG. The unique construction of the female disconnect offers long-term dependability. The brazed seam serrated barrel provides maximum tensile strength. Length 1.04 inches, .29 inches width, maximum insulation .215 inches, tab size .250x.032. The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation for easy installation. Recommended tool ERG4001.

Product Highlights:

Potential Applications:

Search Keywords: RC10250F

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Thomas & Betts

Part No:

RC10-250F

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
