Image is representational - see mfr. specs

RA1147

Sta-Con® Vinyl-Insulated Fork Terminal - Wire Range #22-#16AWG - Material Copper - Tin-Plated Finish - Color Red - Bolt Hole #8 ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The RA1147 is a vinyl-insulated fork terminal for wire range #22 - #16 AWG. Fork terminals enable easy installation because the mounting screw does not have to be completely removed. Length .97 inches, .31 inches width, maximum insulation .150 inches, bolt hole #8. The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation. Vinyl-insulated fork terminals have extra-long PVC insulation sleeves for protection and stress relief at the wire’s flex point. Recommended tool ERG4001.

Product Highlights:

Potential Applications:

Search Keywords: RA1147

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Thomas & Betts

Part No:

RA1147

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
