ER412M4-26A by teledyne relays
Image is representational - see mfr. specs

ER412M4-26A

Teledyne Relays

An established reliability DPDT non-latching relay in a hermetically sealed TO-5 package, featuring a 26.5 Vdc coil and designed for switching loads from dry circuit to 1 ampere. ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ER412M4-26A is an established reliability, DPDT non-latching relay from the 412 series, designed for high-density PC board mounting. It operates with a nominal coil voltage of 26.5 Vdc, features a coil resistance of 1560 ohms, and has a maximum pick-up voltage of 18.0 Vdc. This relay provides a DC resistive contact rating of 1 A at 28 Vdc, with a maximum operate time of 2.0 ms and a release time of 1.5 ms over its operating temperature range of -65°C to +125°C. Its all-welded, uni-frame construction ensures high resistance to shock and vibration. Due to its small size, low power dissipation, and good RF performance, the ER412M4-26A is ideal for demanding applications like T-R switching in handheld radio transceivers.

Search Keywords: ER412M426A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Relays
Part No:
ER412M4-26A
Alias/AKA:
ER412M4-26A/G
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Established Reliability Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
1DC,0.25AC A
Coil Current:
16.99 mA
Coil Resistance:
1.56 KOhm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 0

On Order: 50   can ship 8/20/26
On Order: 22   can ship 8/24/26

MOQ for out of Stock Qty: 13

Factory Lead-Time 26 Weeks

Qty
Unit Price
1
$104.00
5
$102.29
10
$93.02
13
$92.55
25
$87.12
38
$86.69
50 +
$83.57
