FN9264-10-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN9264-10-06

Power Entry Module - Compact - IEC Inlet - 10A - 250V - Quick Connect. ...

View Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

Power all of your components in your circuit using the filtered FN9264-10-06 plug connector from Schaffner. This M connector has 3 M contacts. It has a male type gender. It has a maximum voltage rating of 250 VAC. This connector has a single port. It has a straight body orientation. This device has a maximum current rating of 10 A. It has an operating frequency of 50 to 400 Hz. This part has an operating temperature of -25 to 85 °C. It uses the solder lug termination method. This product is 35 mm long, 46 mm tall and 65.3 mm deep.

Search Keywords: FN92641006

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9264-10-06
Alias/AKA:
811698-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
BOX
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
10 A
Operating Frequency:
50 to 400 Hz
Operating Temperature:
-25 to 85 °C

FREQUENTLY ASKED QUESTIONS

Is FN9264-10-06 RoHS compliant?

Yes, FN9264-10-06 is RoHS compliant.

What is the lead time for FN9264-10-06?

The standard lead time for FN9264-10-06 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 526

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$20.81
10
$17.73
25
$16.46
60
$15.33
120
$14.62
300
$14.59
540 +
$14.14
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
