FN9244-6-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN9244-6-06

The FN9244-6-06 is a high-performance EMC/EMI filter integrated into a standard IEC inlet for superior attenuation in a compact form factor. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The FN9244-6-06 is an IEC inlet filter designed to provide excellent EMC/EMI filtering performance. It operates with a maximum continuous voltage of 250 VAC and is rated for a current of 6 A at 50°C. Key electrical characteristics include an inductance of 4.1 mH, a Cx capacitance of 0.1 µF, and a typical leakage current of 373 µA. This filter is a practical solution for achieving EMI system approval and is well-suited for applications such as portable electronic equipment, single-phase power supplies, and test and measurement equipment.

Search Keywords: FN9244606

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9244-6-06
Alias/AKA:
804061-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
BOX
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
Solder Lug/Faston
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 85 °C

FREQUENTLY ASKED QUESTIONS

Is FN9244-6-06 RoHS compliant?

Yes, FN9244-6-06 is RoHS compliant.

What is the lead time for FN9244-6-06?

The standard lead time for FN9244-6-06 is approximately 16 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 130

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 30

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$8.72
10
$8.70
30
$8.68
60
$6.51
90
$6.08
120 +
$5.95
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
