FN9222S1R-6-06 by te connectivity / schaffner emc
Image is representational - see mfr. specs

FN9222S1R-6-06

TE Connectivity / SCHAFFNER EMC

The FN9222S1R-6-06 is a snap-in IEC inlet filter with an integrated bleed resistor, rated for 6A at 250VAC. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FN9222S1R-6-06 is a general performance IEC inlet filter that combines an IEC inlet and a mains filter in a compact, horizontal snap-in housing. It is designed to operate with a rated current of 6A at 50°C and a maximum continuous voltage of 250VAC. This version includes a 1000 kΩ bleed resistor, an inductance of 0.78 mH, and has a leakage current of 373 µA. With its Faston 6.3 x 0.8mm output terminals and wide operating temperature range of -25°C to +85°C, it provides a practical solution for passing EMI system approvals in applications like portable electronics, single-phase power supplies, and test and measurement equipment.

Search Keywords: FN9222S1R606

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN9222S1R-6-06
Alias/AKA:
803773-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694030
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
Box
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Snap-In
Termination Method:
Spade/Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 85 °C

IN STOCK: 0

On Order: 240   can ship 6/5/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks

Qty
Unit Price
5
$7.07
25
$5.74
120
$5.18
360
$4.77
600
$4.60
1,080
$4.41
2,520
$4.39
5,040 +
$4.37
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
