FN258P-42-33
3-Phase 42 A Input Filter Safety Terminal Block Low Leakage | Schaffner FN258P-42-33 ...
DESCRIPTION
The 800859-SF is a book-style EMC/RFI filter designed for three-phase power distribution systems in inverters and power drive systems. It features a slim space-saving housing with solid safety connector blocks or optional wire output connections, providing excellent attenuation performance across a wide range of current ratings from 7 A to 250 A at 50°C. The filter operates at DC to 60 Hz with maximum continuous operating voltages of 3×520/300 VAC for standard versions, delivering power loss ranging from 9 W to 79 W depending on the current rating. Leakage current specifications vary from 2.0 mA to 3.5 mA at 520/760 VAC/50 Hz, with weights ranging from 1.0 kg to 19 kg. This filter is widely used in industrial power conditioning applications where EMC compliance and reliable filtering of harmonic distortion are essential for protecting sensitive equipment and ensuring regulatory compliance.
Search Keywords: FN258P4233
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is FN258P-42-33 discontinued?
Yes, FN258P-42-33 from Te Connectivity / Schaffner Emc is discontinued (end-of-life June 2024). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.
What replaces FN258P-42-33?
The recommended replacement for FN258P-42-33 is FN3288-40-33-C21-R65 from TE Connectivity / SCHAFFNER EMC, available from Master Electronics.
Is FN258P-42-33 RoHS compliant?
Yes, FN258P-42-33 is RoHS compliant.
What is the lead time for FN258P-42-33?
The standard lead time for FN258P-42-33 is approximately 10 days. In-stock quantities ship from Master Electronics.
IN STOCK: 1
Can Ship immediately
You may purchase all in-stock quantity of 1
Stock lot only: 1
Minimum Order Quantity: 3
Datasheet
