FN2090-10-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN2090-10-06

Power Line Filter - Chassis - 10 A - 250 VAC - EMI - RFI - Quick Connect - 8 mH - 0.47 µF. ...

View Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The FN2090-10-06 is a 1-phase 10A multi-stage EMI Filter with excellent attenuation performance and it is designed for easy and fast chassis mounting. It provides an exceptional conducted attenuation performance, based on chokes with high permeable core material and excellent thermal behaviour. The filter is designed for noisy applications requiring excellent filter performance. The higher inductivity versus amperage offers increased attenuation performance with the same form factor compared to FN2060 and FN2080 filter series.

Search Keywords: FN20901006

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN2090-10-06
Alias/AKA:
802442-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
BOX
Mounting:
Flange Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
10 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 100 °C
Dimension:
57.5 x 113.5 x 45.4 mm

FREQUENTLY ASKED QUESTIONS

What replaces FN2090-10-06?

The recommended replacement for FN2090-10-06 is FN2310H-10-06 from TE Connectivity / SCHAFFNER EMC, available from Master Electronics.

Is FN2090-10-06 RoHS compliant?

Yes, FN2090-10-06 is RoHS compliant.

What is the lead time for FN2090-10-06?

The standard lead time for FN2090-10-06 is approximately 16 weeks. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 342

Can Ship immediately

Manufacturer Stock: 79   can ship 10/19/26

Factory Lead-Time 16 Weeks can ship 1/26/27

Price (USD)

Qty
Unit Price
1
$54.59
5
$48.79
20
$40.54
40
$40.34
60
$40.24
100
$40.14
260 +
$40.04
