FN2030B-20-06 by te connectivity / schaffner emc
Image is representational - see manufacturer specifications
TE Connectivity / SCHAFFNER EMC Authorized Distributor

FN2030B-20-06

Power Line Filter General Purpose EMI 0Hz to 400Hz 20A 250VAC Solder Lug Flange Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The SCHAFFNER EMC FN2030B-20-06 is a high-performance power line filter designed for general-purpose applications. With an impressive frequency range of 0Hz to 400Hz, this filter effectively suppresses electromagnetic interference (EMI) across a wide spectrum. Featuring a current rating of 20A and a voltage rating of 250VAC, this filter ensures reliable and efficient operation in a variety of electrical systems. The solder lug flange mount design allows for easy installation and secure connection, minimizing the risk of disconnection or malfunction. Ideal for use in industrial, commercial, and residential settings, the SCHAFFNER EMC FN2030B-20-06 power line filter guarantees cleaner and safer power supply, protecting sensitive equipment and devices from potential EMI damage.

Search Keywords: FN2030B2006

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN2030B-20-06
Alias/AKA:
802523-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8548000000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
BOX
Mounting:
Flange Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
20 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 100 °C
Dimension:
54 x 40.3 mm

FREQUENTLY ASKED QUESTIONS

What replaces FN2030B-20-06?

The recommended replacement for FN2030B-20-06 is 20EHZ1 from TE Connectivity / Corcom Brand, available from Master Electronics.

Is FN2030B-20-06 RoHS compliant?

Yes, FN2030B-20-06 is RoHS compliant.

What is the lead time for FN2030B-20-06?

The standard lead time for FN2030B-20-06 is approximately 23 weeks. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 124

Ships today, if you order in

On Order: 140   can ship 1/18/27

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
1
$40.70
5
$38.09
20
$35.84
40
$34.71
60
$34.05
100
$32.27
260 +
$29.86
