Image is representational - see manufacturer specifications
TE Connectivity / Raychem Brand Authorized Distributor

TXR54AB00-2216AI

Backshell - Heat Shrink Adapter - 1.468" (37.29mm) Outside Diameter - Shell Size 22 - 1 5/16-18 UNEF Thread Size - 180° Cable Exit - Entry Size 16. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TXR54AB00-2216AI from TE Connectivity / Raychem Brand is shielded backshell, heat shrink adapter with shell size 22, entry size 16 and ring to suit single braid. This backshell has 1.468" (37.29mm) outside diameter, 1 5/16-18 UNEF thread size and 180° cable exit. The TXR54AB00-2216AI include: 1 backshell, 1 braid and 1 tinel ring. Operating temperature range is from -65 to 175 °C ( -85 to 347 °F ).

Search Keywords: TXR54AB002216AI

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
TXR54AB00-2216AI
Alias/AKA:
799612-000
Unit of Measure:
Per Each
RoHS:
No
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Shell Size:
22
Angular Function:
180 °
Body Material:
Aluminum Alloy
Body Plating:
Olive Drab Cadmium Over Electroless Nickel
Entry Size:
25.4 mm
Operating Temperature:
-65 to 175 °C

FREQUENTLY ASKED QUESTIONS

Is TXR54AB00-2216AI RoHS compliant?

No, TXR54AB00-2216AI is not RoHS compliant.

What is the lead time for TXR54AB00-2216AI?

The standard lead time for TXR54AB00-2216AI is approximately 27 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 48

Can Ship immediately

On Order: 100   can ship 1/18/27

MOQ for out of Stock Qty: 13

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
1
$190.99
5
$174.71
10
$167.52
13
$165.86
25
$164.21
38
$162.59
50 +
$160.98
