TXR40AB00-1007AI by te connectivity / raychem brand

TXR40AB00-1007AI

TE Connectivity / Raychem Brand

Backshell - Ruggedized - 0.827" (21.00mm) Diameter - Shell Size 11, B - M15x1 Thread - 180° Cable Exit - Tinel Lock - Shielded - Olive Drab. ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TXR40AB00-1007AI from TE Connectivity / Raychem Brand is shielded ruggedized backshell with 0.827" (21.00mm) outside diameter, shell size 11, B and M15x1 thread. This olive drab backshell has 180° cable exit and tinel lock. Cable entry diameter range is from .01 to .44 in (.2 to 11.1 mm). Operating temperature range is from -65 to 175 °C ( -85 to 347 °F ).

Product Highlights:

  • Style = Tinel Lock
  • Connector Code = 40
  • Straight
  • Shell Size = 11, B
  • Entry Size = 7

Search Keywords: TXR40AB001007AI

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
TXR40AB00-1007AI
Alias/AKA:
019147-000
RoHS:
No
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Shell Size:
10
Angular Function:
180 °
Coupling:
Spin
Body Material:
Aluminum Alloy
Body Plating:
Cadmium Over Electroless Nickel
Entry Size:
7 mm
Operating Temperature:
N/A

IN STOCK: 7

Can Ship immediately

Factory Lead-Time 34 Weeks

Qty
Unit Price
1
$149.56
5
$124.63
10
$110.71
15
$107.21
25
$106.67
50 +
$102.82
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
