D-609-14 by te connectivity / raychem brand
Image is representational - see manufacturer specifications
TE Connectivity / Raychem Brand Authorized Distributor

D-609-14

Splice 12-16AWG Copper Alloy 7.11mm Nickel Loose ...

View Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

MiniSeal wire-to-wire splicing products offer solutions for hundreds of aerospace and defense applications. These environment-resistant splices provide excellent reliability, long term performance, MIL-S-81824/1 qualification, and a low installed cost. MiniSeal crimp splices consist of a plated copper crimp barrel and a separate, heat-shrinkable, transparent sealing sleeve. They can be used on a combination of wires, from 1:1 to 10:10. MiniSeal splices are one of the smallest, lightest, and most environment resistant splices available. They preserve the electrical integrity of the splice by preventing the penetration of liquids and the resulting chemical and galvanic corrosion.

Product Highlights:

  • Splice
  • Not Sealed
  • Splice Type = Butt
  • Butt Splice Type = Standard
  • Body Style = DuraSeal

Search Keywords: D60914

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
D-609-14
Alias/AKA:
680334-000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BOX
Type:
Splice Terminal
Color:
N/A
Body Material:
Copper Alloy

FREQUENTLY ASKED QUESTIONS

Is D-609-14 RoHS compliant?

Yes, D-609-14 is RoHS compliant.

What is the lead time for D-609-14?

The standard lead time for D-609-14 is approximately 25 days. In-stock quantities ship from Master Electronics.

IN STOCK: 714

Can Ship immediately

On Order: 3,000   can ship 3/1/27

Minimum Order Quantity: 10

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
10
$3.78
50
$3.43
250
$2.85
500
$2.75
1,000
$2.36
3,000
$2.18
5,000
$2.17
8,000 +
$2.16
Supplier's Standard Package
