Image is representational - see mfr. specs
55A0121-20-9/96
TE Connectivity / Raychem BrandSpec 44, Spec 55 and Spec RCW Wire and Cable ...
RoHS Compliant
Pack Packaging
Certificate of Compliance Guarantee
DESCRIPTION
Spec 44, Spec 55 and Spec RCW Wire and Cable
Product Highlights:
- Cable Type = Spec 55
- Wire Source = United Kingdom, United States
- Cable Style = Primary
- Wire Size (AWG/CM) = 20 AWG
- Voltage Rating = 600 VAC
Search Keywords: 55A012120996
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
55A0121-20-9/96
Alias/AKA:
316067-000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
1
Package Type:
Pack
Cable Type:
Spec 55
Strand Size:
32 AWG
Operating Temperature Range:
-65 – 150 °C
Wire Color:
White with Blue Stripe
Cable Style:
Primary
Wire Size:
20 AWG
Voltage Rating:
600 VAC
Overall Outside Diameter:
.102 in
Number of Conductors:
2
Number of Strands:
19
Product Type:
Wire Lead
Conductor Material:
Tin-Plated Copper
Conductor Diameter:
.94 mm
Product Classification:
Cable - High Performance - Spec 44, 55 and RCW
Insulation Material:
Radiation-Crosslinked, Modified ETFE
IN STOCK: 0
MOQ for out of Stock Qty: 500
Factory Lead-Time 15 Weeks
Qty
Unit Price
500
$1.53
1,000
+
$1.43
Datasheet
TE - Raychem - 55A Hook-up Wire - Product Specification - Rev 5 - 2022-07-06
