5053222025 by te connectivity / raychem brand
Image is representational - see manufacturer specifications
TE Connectivity / Raychem Brand Authorized Distributor

5053222025

5053222025 is a flexible, flame-retardant, general-purpose polyolefin heat-shrinkable tubing with a 2:1 shrink ratio. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 5053222025 is a general-purpose, heat-shrinkable tubing from the RNF-100 series, designed for insulation, strain relief, and identification of wires and components. It features a 2:1 shrink ratio and operates effectively in a temperature range of -55°C to 135°C. This tubing provides superior abrasion and solvent resistance, is flexible to conform to irregular shapes, and meets military standard AMS-DTL-23053/5. It is widely used for jacketing wire bundles, protecting light-duty harnesses, and color-coding electrical connections in demanding environments.

Search Keywords: 5053222025

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
5053222025
Alias/AKA:
RNF-100-1/2-6-STK
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
3926909989
COO:
CZ
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
BAG
Resistant To:
Abrasion , Fluids , Mechanical Damage , Strain
Recovered Inside Diameter (Max):
.25 in, 6.4 mm
Packaging Method:
Bag/Box
Flexibility:
Flexible
Shrink Ratio:
2:1
Recovery Temperature:
121 °C
Expanded Inside Diameter (Min):
.5 in, 12.7 mm
Low Outgassing:
No
Material:
Irradiated Modified Polyolefin
Recovered Wall Thickness (Nominal):
.026 in, .65 mm
Color:
Blue
Product Source:
Czech Republic
Operating Temperature Range:
-55 – 135 °C
Fluid Type:
Gasoline , Hydraulic Fluid , Lubricating Oil , Water
Voltage (Max):
.6 kV
Flammability:
Flame-Retardant
Recovered Wall Thickness (Tolerance):
.012 in, .3 mm
Size Range:
.25 – .5 in, 6.4 – 12.7 mm
Product Family:
RNF-100
Fluid Resistance:
Splash Protection
Cut Length:
48.031 in, 1220 mm
Shrink Temperature (Min):
95 °C
Applicable Region:
Global
Wall Type:
Single

FREQUENTLY ASKED QUESTIONS

Is 5053222025 RoHS compliant?

Yes, 5053222025 is RoHS compliant.

What is the lead time for 5053222025?

The standard lead time for 5053222025 is approximately 15 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

MOQ for out of Stock Qty: 180

Multiple: 30

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
180
$5.13
360
$3.16
540
$2.50
720 +
$2.45
