301A513-71-0
TE Connectivity / Raychem BrandMolded Parts ...
RoHS Compliant
Bag Packaging
Certificate of Compliance Guarantee
DESCRIPTION
Molded Parts
Product Highlights:
- Transition
- Family Name = 301A5
- Transition Type = Slimline T
- 2 Branches/Legs
- General Purpose Application
Search Keywords: 301A513710
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
301A513-71-0
Alias/AKA:
551947-000
RoHS:
Yes
HTS:
3926909989
COO:
MX
ECCN:
EAR99
Supplier Standard Pack
1
Package Type:
Bag
Transition Type:
T-Transition
Size Code:
513
Molded Part Shape:
Slimline T Shape
Breakout Angle:
90
Special Requirements:
Flame Retarded
Material Systems Code:
10
Wire/Cable Sm Branch OD:
24 mm
Product Type:
Molded Part
Material:
Semi-Rigid Modified Polyolefin
Flammability:
Flame-Retardant
Material Code:
71
Adhesive Type:
Adhesive Purchased Separately
Adhesive Options:
/180 Precoat
Operating Temperature Range:
-55 – 135 °C
Formcode des Formteils:
301A
Pliancy:
Flexible
Color:
Black
Molded Part Shape Code:
301A
Wire/Cable OD:
1.42 in
Adhesive Pre-Coat:
No
Molded Part Type:
Breakouts/Transitions
Wire/Cable Main Branch OD:
24 mm
Number of Branches/Legs:
3
Inside Diameter Range (Leg 2):
20.1 – 40.1 mm
Fluid/Chemical Resistance:
Occasional exposure to fluids
Shrink Ratio Type:
High
Packaging Method:
Bag/Box
Power Cable Accessory:
No
Inside Diameter Range (Leg 1):
20.1 – 40.1 mm
Inside Diameter Range (Body):
.79 – 2.37 in, 20.1 – 60.2 mm
Resistant To:
Flexing
IN STOCK: 131
Can Ship immediately
MOQ for out of Stock Qty: 32
Factory Lead-Time 8 Weeks
Qty
Unit Price
1
$121.45
10
$63.68
25
$45.12
32
$44.89
63
$44.67
94
$44.45
125
+
$44.22
Please Note:
Tariffs may apply for U.S. shipments
Datasheet
