T9AS5D22-5 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

T9AS5D22-5

The T9AS5D22-5 is a 1 Form C general-purpose power relay with a 5VDC coil, AgCdO contacts, and combined PCB/Quick Connect terminals. ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The T9AS5D22-5 is a T9A series general-purpose power relay designed for high-current switching. It features a 1 Form C (CO) contact arrangement with silver cadmium oxide (AgCdO) contacts, rated for 20A/10A at 240VAC. The relay is operated by a 5VDC coil with a nominal power consumption of 1W and a resistance of 25 Ohms. This model is housed in a wash-tight plastic case and offers flexible mounting with both PCB through-hole pins and 0.250" Quick Connect (QC) terminals. With a maximum operate and release time of 15ms each, it is suitable for applications like HVAC, appliances, and industrial controls.

Product Highlights:

  • T9A Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: T9AS5D225

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T9AS5D22-5
Alias/AKA:
3-1419104-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
OTHER
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
Quick Connect/PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 85 °C

FREQUENTLY ASKED QUESTIONS

What replaces T9AS5D22-5?

The recommended replacement for T9AS5D22-5 is T91P5D22-5 from TE Connectivity / P&B Brand, available from Master Electronics.

Is T9AS5D22-5 RoHS compliant?

Yes, T9AS5D22-5 is RoHS compliant.

What is the lead time for T9AS5D22-5?

The standard lead time for T9AS5D22-5 is approximately 18 weeks. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 971

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$7.61
25
$6.98
50
$6.70
100
$6.43
250
$6.07
500
$5.80
1,000
$5.53
2,500 +
$5.21
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
