T92S7A22-24 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

T92S7A22-24

High Power PCB Relay - 2 form A (2 NO) - 24VAC Coil - 30A Contact Rating - 600VAC Switching - Sealed Plastic Case - 0.250" Quick Connect. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The T92S7A22-24 from TE Connectivity / P&B Brand is chassis mount high power PCB relay with 2 form A (2 NO) contact arrangement, 24VAC coil voltage and 36.6 Ohms coil resistance. This sealed plastic case relay has silver cadmium oxide (AgCdO) contacts, 30A contact current rating, 600VAC maximum switching voltage and 0.250" (6.3mm) quick connect termination. Operating temperature range is from -55°C to 65°C.

Product Highlights:

  • T92 Series
  • Contact Arrangement = 2 Form A, DPST-NO, 2 N/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC

Search Keywords: T92S7A2224

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T92S7A22-24
Alias/AKA:
1393212-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
BAG
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPST-NO
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 65 °C

FREQUENTLY ASKED QUESTIONS

Is T92S7A22-24 RoHS compliant?

Yes, T92S7A22-24 is RoHS compliant.

What is the lead time for T92S7A22-24?

The standard lead time for T92S7A22-24 is approximately 23 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

Manufacturer Stock: 24,960   can ship 8/28/26

On Order: 1,320   can ship 9/28/26

Factory Lead-Time 23 Weeks can ship 1/21/27

Price (USD)

Qty
Unit Price
1
$27.36
5
$22.55
10
$22.49
30
$22.11
60
$22.05
120
$22.00
270 +
$21.94
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
