RTB34012F by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

RTB34012F

Power Relay 12VDC 12A SPST-NO(29mm 12.7mm 15.7mm) THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TE Connectivity / P&B Brand part RTB34012F is a reliable power relay designed for a wide range of applications. With a coil voltage of 12VDC and a contact rating of 12A, this SPST-NO relay is suitable for high-power electrical circuits. The compact size of 29mm x 12.7mm x 15.7mm makes it easy to integrate into electronic assemblies using Through-Hole Technology (THT). Trust the RTB34012F for dependable and efficient performance in your next project.

Product Highlights:

  • RT1 Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 12 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: RTB34012F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RTB34012F
Alias/AKA:
2-1419108-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
BOX
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
12 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
360 Ohm

FREQUENTLY ASKED QUESTIONS

Is RTB34012F RoHS compliant?

Yes, RTB34012F is RoHS compliant.

What is the lead time for RTB34012F?

The standard lead time for RTB34012F is approximately 23 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 4,400

Can Ship immediately

MOQ for In Stock Qty: 20

MOQ for out of Stock Qty: 500

Multiple: 20

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
20
$4.69
100
$4.64
260
$4.60
500
$4.58
1,000
$4.57
1,500
$4.56
2,000 +
$4.55
Supplier's Standard Package
