PRD-3AY0-120 by te connectivity / p-b brand

PRD-3AY0-120

TE Connectivity / P&B Brand

Power Relay - Open Style - 1 form X (1 NO-DM) - 120VAC Coil - 25A Contact Rating - 600VAC/125VDC Switching - Screw Termination - Chassis Mount. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PRD-3AY0-120 from TE Connectivity / P&B Brand is chassis mount power relay (open style) with 1 form X (1 NO-DM) contact arrangement, 120VAC coil voltage, 85 mA coil current and 290 Ohms coil resistance. This relay has silver (Ag) contacts, 25A contact current rating, 600VAC/125VDC maximum switching voltage and screw termination. Operating temperature range is from -55°C to 45°C.

Product Highlights:

  • PRD Series
  • Contact Arrangement = 1 Form X, SPST-NO-DM, 1 N/O Bridge Contact
  • Contact Current Rating = 25 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 120 VAC

Search Keywords: PRD3AY0120

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
PRD-3AY0-120
Alias/AKA:
7-1393127-9
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
SPST-NO-DM
Mounting:
N/A
Termination Style:
Screw Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 45 °C

IN STOCK: 89

Can Ship immediately

Factory Lead-Time 18 Weeks

Qty
Unit Price
1
$42.88
5
$33.43
20
$31.72
40
$31.02
60
$30.87
100
$30.71
260 +
$30.56
Suppliers Standard Package
