PBH14012 by te connectivity / p-b brand
Image is representational - see mfr. specs

PBH14012

TE Connectivity / P&B Brand

The PBH14012 is a miniature, high-temperature, general-purpose power PCB relay featuring a 1 Form C contact and a 12VDC coil. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PBH14012 is a miniature power PCB relay designed for high-temperature environments up to 105°C. It features a single pole, 1 Form C (CO) contact made of AgNi 90/10 material, operated by a 12VDC coil that has a resistance of 400 Ω and a rated power of 360 mW. This relay handles a rated current of 6A at 250VAC, with a maximum breaking capacity of 1500VA. As a product in accordance with IEC 60335-1, it is well-suited for applications in white goods and other domestic appliances.

Search Keywords: PBH14012

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
PBH14012
Unit of Measure:
Per Each
RoHS:
Yes
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1050
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-20 to 105 °C
Coil Resistance:
400 Ohm

IN STOCK: 50,730

Can Ship immediately

MOQ for In Stock Qty: 1050

MOQ for out of Stock Qty: 1050

Multiple: 1050

Factory Lead-Time 28 Weeks

Qty
Unit Price
10
$4.15
25
$3.32
100
$2.93
263
$2.65
525
$2.59
788
$2.58
1,050 +
$2.57
Suppliers Standard Package
