KUP-14A55-24 by te connectivity / p-b brand

KUP-14A55-24

TE Connectivity / P&B Brand

Power Relay 24VAC 10A 3PDT(48.4x38.9x35.7)mm Bracket ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part KUP-14A55-24 is a high-quality power relay designed for reliable and efficient electrical switching applications. It operates at a voltage of 24VAC and has a maximum current rating of 10A. With its 3PDT (3 pole, double throw) configuration, this power relay offers versatile switching options for various circuit setups. The relay is enclosed within a compact and durable housing measuring at (48.4x38.9x35.7)mm, ensuring easy installation in tight spaces. It also comes with a sturdy bracket for secure mounting. Whether used in industrial automation, HVAC systems, or control panels, the TE Connectivity / P&B Brand power relay KUP-14A55-24 delivers exceptional performance and reliability in power switching applications.

Product Highlights:

  • KUP Series
  • Contact Arrangement = 3 Form C, 3PDT, 3 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC

Search Keywords: KUP14A5524

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUP-14A55-24
Alias/AKA:
1393118-2
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
3PDT
Maximum Current Rating:
10 A
Mounting:
Bracket Mount
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 45 °C
Coil Resistance:
72 Ohm

IN STOCK: 285

Can Ship immediately

Factory Lead-Time 18 Weeks

Qty
Unit Price
1
$24.63
10
$18.23
25
$17.23
50
$17.03
100
$16.95
250
$16.34
500 +
$16.26
Suppliers Standard Package
