KUMP-14D18-24 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

KUMP-14D18-24

Power Relay 24VDC 15A 3PDT(38.89x35.71x49.99)mm Socket ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TE Connectivity / P&B Brand part KUMP-14D18-24 is a high-quality power relay designed for various industrial applications. It operates on a 24VDC input voltage and is capable of handling up to 15A of current. This 3PDT (3 Form C) relay is compact, with dimensions of 38.89x35.71x49.99mm, making it easy to integrate into your existing systems. The relay is compatible with a socket, ensuring easy installation and maintenance. With its reliable performance and durable construction, the KUMP-14D18-24 power relay is an ideal choice for power switching and control purposes.

Product Highlights:

  • KUMP Series
  • Contact Arrangement = 3 Form C, 3PDT, 3 C/O
  • Contact Current Rating = 15 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: KUMP14D1824

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUMP-14D18-24
Alias/AKA:
9-1393116-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TRAY
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
3PDT
Maximum Current Rating:
15 A
Mounting:
Plain Case
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
472 Ohm

FREQUENTLY ASKED QUESTIONS

Is KUMP-14D18-24 RoHS compliant?

Yes, KUMP-14D18-24 is RoHS compliant.

What is the lead time for KUMP-14D18-24?

The standard lead time for KUMP-14D18-24 is approximately 27 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 300   can ship 10/12/26
On Order: 300   can ship 10/19/26

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
1
$38.16
5
$30.58
10
$29.98
25
$29.40
50
$29.32
100
$29.25
250 +
$29.18
Supplier's Standard Package
