K10P-11DT5-12 by te connectivity / p-b brand
Image is representational - see manufacturer specifications
TE Connectivity / P&B Brand Authorized Distributor

K10P-11DT5-12

Electromechanical Power Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TE Connectivity / P&B Brand K10P-11DT5-12 is a high-performance electromechanical power relay designed for robust applications. It features a dependable 12V DC coil and a single-pole double-throw (SPDT) contact arrangement, making it suitable for a wide range of switching tasks. Engineered for reliability, this relay is perfect for applications requiring high contact ratings and long electrical endurance. Its compact design ensures easy integration into electrical systems, while its quality construction provides reliable operation in demanding environments. Ideal for use in industrial automation, HVAC systems, and automotive applications, the K10P-11DT5-12 relay offers superior performance and versatility, ensuring seamless control and efficiency.

Product Highlights:

  • K10 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 15 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: K10P11DT512

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
K10P-11DT5-12
Alias/AKA:
5-1393144-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TRAY
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Flange Mount
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
160 Ohm

FREQUENTLY ASKED QUESTIONS

What replaces K10P-11DT5-12?

The recommended replacement for K10P-11DT5-12 is 258-62B200 from TE Connectivity / Midtex Brand, available from Master Electronics.

Is K10P-11DT5-12 RoHS compliant?

Yes, K10P-11DT5-12 is RoHS compliant.

What is the lead time for K10P-11DT5-12?

The standard lead time for K10P-11DT5-12 is approximately 25 days. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 525

Can Ship immediately

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
1
$24.79
5
$17.86
10
$15.80
25
$15.50
50
$15.19
100
$15.04
250 +
$14.03
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
