154767
SMCB 80 M AB VV 7-03 CL * 0007 137 E004 ...
DESCRIPTION
154767 is an 80-pin right-angle male SMC connector designed for high-performance board-to-board and cable interconnection applications. The connector features SMT (surface mount technology) termination with dual-row contact arrangement on a 1.27 mm grid pitch, supporting data rates up to 3 Gbit/s with differential signal transmission capability. Key technical characteristics include a compact form factor with dimensions of 53.95 mm (A), 55.88 mm (B), and 53.55 mm (C), location pegs for precise board placement, and a black insulation body for reliable visual recognition during assembly. The connector employs double-sided spring contacts for superior contact reliability and virtually continuous impedance profile, enabling secure high-speed data transmission. This connector is ideal for modern electronic systems requiring compact, secure, and reliable interconnections with high signal integrity and current-carrying capacity in space-constrained applications.
Search Keywords: 154767
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is 154767 RoHS compliant?
Yes, 154767 is RoHS compliant.
What is the lead time for 154767?
The standard lead time for 154767 is approximately 36 weeks. In-stock quantities ship from Master Electronics.
IN STOCK: 82
Can Ship immediately
MOQ for In Stock Qty: 15
MOQ for out of Stock Qty: 15
Factory Lead-Time 36 Weeks
Datasheet
