DT06-4S-C017 by te connectivity / deutsch automotive
Image is representational - see mfr. specs

DT06-4S-C017

TE Connectivity / Deutsch Automotive

PLG, 4P, GRY, BLOCKED

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / Deutsch Automotive part DT06-4S-C017 is a high-quality 4-pin (4P) connector featuring a gray color with blocked terminals. This weatherproof connector is perfect for automotive applications where reliability and durability are essential.

Search Keywords: DT064SC017

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT06-4S-C017
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Operating Voltage:
250 VAC
Mating Pin Diameter:
.0625 in, 1.59 mm
Sealable:
Yes
Agency/Standard:
SAE J2030
Primary Product Color:
Gray
Mounting Feature:
Without
Operating Temperature (Max):
125 °C, 257 °F
Circuit Application:
Power & Signal
Contact Current Rating (Max):
13 A
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Primary Locking Feature:
Integrated in Housing
Row-to-Row Spacing:
.359 in, 9.12 mm
Terminal Position Assurance:
Yes
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Body Material:
PA GF
Blank Cavity Position:
4
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Connector System:
Wire-to-Wire
Polarized:
Yes
Packaging Method:
Box
Cable Exit Angle:
180 °
Serviceable:
Yes
Connector Position Assurance Capable:
No
Width:
.82 in, 20.83 mm
Packaging Quantity:
900
Number of Rows:
2
Strain Relief:
Add By Accessory
Connector & Housing Type:
Housing for female terminals
Height:
.771 in, 19.58 mm
Hybrid Connector:
No
Length:
1.328 in, 33.73 mm
Centerline (Pitch):
.175 in, 4.45 mm
Degree of Protection:
IP68 , IP6K9K
Number of Positions:
4

IN STOCK: 0

On Order: 1,000   can ship 5/6/26

Minimum Order Quantity: 10

Factory Lead-Time 17 Weeks

Qty
Unit Price
10
$2.36
100
$2.05
250
$1.99
500 +
$1.95
Log in for special pricing Click for Quote Price Match Request
