DT06-2S-C017 by te connectivity / deutsch automotive
Image is representational - see manufacturer specifications
TE Connectivity / Deutsch Automotive Authorized Distributor

DT06-2S-C017

PLG, 2P, GRY, BLOCKED ...

View Datasheet Ask the Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

TE Connectivity / Deutsch Automotive part DT06-2S-C017 is a compact and reliable electrical plug designed for automotive applications. Featuring a two-pin configuration, it offers excellent connectivity and is specifically intended for use in gray-colored accessories. This plug is engineered to be resistant to moisture and dust, ensuring reliable performance even in harsh environments. Additionally, DT06-2S-C017 is equipped with a blocked design, making it a secure choice for preventing unintended disconnections.

Search Keywords: DT062SC017

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT06-2S-C017
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Cable Exit Angle:
180 °
Blank Cavity Position:
2
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Sealable:
Yes
Hybrid Connector:
No
Length:
1.278 in, 32.46 mm
Connector & Housing Type:
Housing for female terminals
Agency/Standard:
SAE J2030
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Operating Temperature (Max):
125 °C, 257 °F
Operating Voltage:
250 VAC
Height:
.621 in, 15.77 mm
Mating Pin Diameter:
.0625 in, 1.59 mm
Strain Relief:
Add By Accessory
Packaging Method:
Box
Serviceable:
Yes
Width:
.591 in, 15.01 mm
Primary Product Color:
Gray
Polarized:
Yes
Number of Rows:
1
Circuit Application:
Power & Signal
Connector Position Assurance Capable:
No
Primary Locking Feature:
Integrated in Housing
Terminal Position Assurance:
Yes
Packaging Quantity:
1600
Centerline (Pitch):
.215 in, 5.46 mm
Body Material:
PA GF
Mounting Feature:
Without
Connector System:
Wire-to-Wire
Number of Positions:
2
Degree of Protection:
IP68 , IP6K9K
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Contact Current Rating (Max):
13 A

FREQUENTLY ASKED QUESTIONS

Is DT06-2S-C017 RoHS compliant?

Yes, DT06-2S-C017 is RoHS compliant.

What is the lead time for DT06-2S-C017?

The standard lead time for DT06-2S-C017 is approximately 13 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 580

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
25
$1.79
100
$1.17
250
$1.15
500
$1.12
1,000
$1.11
2,500
$1.10
5,000
$1.09
7,500 +
$1.08
Log in for special pricing Click for Quote Price Match Request
