DT06-12SC-EP06 by te connectivity / deutsch automotive

Image is representational - see mfr. specs

DT06-12SC-EP06

Name: DT06-12SC-EP06
Brand: Te Connectivity Deutsch Automotive
SKU: 50873692
Price: 28.7 USD
Availability: InStock

TE Connectivity / Deutsch Automotive

PLG, 12P, GRN, N, SEAL RET,ENH KEY,CAP,C ...

Datasheet

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The DT06-12SC-EP06 is a 12-way sealed plug connector from TE Connectivity's DEUTSCH DT series, featuring enhanced seal retention design and C key configuration in green color with an integrated end cap. This connector accepts contact size 16 rated for 13 amps and accommodates 14–20 AWG (2.50–0.50 mm²) wire gauges, with a rectangular thermoplastic housing and integrated latch for secure mating. The enhanced seal retention design incorporates a groove on the connector housing that secures the interface seal, smaller ribs on a taller seal for secure fit, and compatibility with the WI25-P012 green wedgelock for robust contact alignment and retention. The connector is field-proven to withstand heavy vibration, dirt, chemicals, and water spray in harsh environments, and is intermateable with older DEUTSCH DT connectors. Common applications include industrial control systems, commercial transportation, and heavy equipment where sealed, reliable connections are critical for maintaining uptime and reducing replacement costs.

Product Highlights:

Potential Applications:

Search Keywords: DT0612SCEP06

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / Deutsch Automotive

Part No:

DT06-12SC-EP06

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
