DT04-08PA-CL03 by te connectivity / deutsch automotive
Image is representational - see mfr. specs

DT04-08PA-CL03

TE Connectivity / Deutsch Automotive

REC, 8P, GRY, E, FLANGE, A

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

REC, 8P, GRY, E, FLANGE, A

Search Keywords: DT0408PACL03

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT04-08PA-CL03
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Length:
1.798 in, 45.67 mm
Centerline (Pitch):
.359 in, 9.12 mm
Number of Rows:
2
Serviceable:
Yes
Operating Voltage:
250 VAC
Row-to-Row Spacing:
.175 in, 45.45 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Degree of Protection:
IP68 , IP6K9K
Primary Locking Feature:
Integrated in Housing
Hybrid Connector:
No
Height:
1.398 in, 35.51 mm
Circuit Application:
Power & Signal
Connector Code:
A
Cable Exit Angle:
180 °
Operating Temperature (Max):
125 °C, 257 °F
Agency/Standard:
SAE J2030
Polarized:
Yes
Connector Position Assurance Capable:
No
Blank Cavity Position:
0
Packaging Method:
Box
Terminal Position Assurance:
Yes
Mating Pin Diameter:
.0625 in, 1.59 mm
Number of Positions:
8
Contact Current Rating (Max):
13 A
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Connector Mounting Type:
Bulkhead , Fixing Screw , Panel Mount
Width:
2.165 in, 54.99 mm
Body Material:
PA GF
Connector & Housing Type:
Housing for Male Terminals
Packaging Quantity:
200
Mounting Feature:
With
Connector System:
Wire-to-Wire
Sealable:
Yes
Primary Product Color:
Gray
Strain Relief:
Add By Accessory

IN STOCK: 207

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 10 Weeks

Qty
Unit Price
5
$6.13
50
$4.98
100
$4.76
250
$4.56
500
$4.37
1,000
$4.25
2,500
$4.14
5,000 +
$4.08
Log in for special pricing Click for Quote Price Match Request
