6VM4 by te connectivity / corcom brand
Image is representational - see manufacturer specifications
TE Connectivity / Corcom Brand Authorized Distributor

6VM4

Power Entry Module EMI/RFI Filtered M 3 POS 240VAC 6A Fuse/Voltage Selector ST 1 Port ...

View Datasheet Ask the Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 6VM4 is a non-filtered slim power entry module designed for minimal depth behind panel installation, featuring a 4-position voltage selector for 100V, 120V, 230V, and 240V operation. This module provides a rated maximum voltage of 250 VAC at 50/60 Hz operating frequency, with a rated current of 6A at 120 VAC (non-switched configuration). The module includes a reversible fuse holder accepting either one 0.25 x 1.25" or two 5 x 20mm fuses, and features an IEC 60320-1 C14 line inlet with 0.110" backplate terminals. The 6VM4 is UL recognized, CSA certified, and VDE approved, making it suitable for a wide range of industrial and commercial power distribution applications where compact form factor and multiple voltage selection are required.

Product Highlights:

  • Filter - EMI/RFI
  • Filter Type = Power Entry (Filtered/Unfiltered)
  • M (3-6 Amp) Series
  • General Purpose Application
  • Mount Style = Mounting Ears (Horizontal)

Search Keywords: 6VM4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Corcom Brand
Part No:
6VM4
Alias/AKA:
3-6609128-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8537109170
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
24
Package Type:
Pack
Type:
EMI/RFI Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Flange Mount
Termination Method:
Quick Connect
Maximum Voltage Rating:
240 VAC
Maximum Current Rating:
6 A
Operating Frequency:
N/A
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 6VM4 RoHS compliant?

Yes, 6VM4 is RoHS compliant.

What is the lead time for 6VM4?

The standard lead time for 6VM4 is approximately 28 days. In-stock quantities ship from Master Electronics.

IN STOCK: 73

Can Ship immediately

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
1
$43.85
5
$42.39
24
$33.32
48
$32.34
72
$32.26
120
$32.18
264 +
$32.10
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
