966144-4

Name: 966144-4 Te Connectivity Amp Brand Ferrules
Brand: Te Connectivity Amp Brand
SKU: 10532050
Availability: InStock

FER,WIRE,DBL,PL SLV,1.00/18,L8,RED,LP ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

The 966144-4 is a double wire ferrule designed to terminate two 1.00 mm² flexible leads simultaneously with a gas-tight crimped connection. It features a copper sleeve with polypropylene plastic collar rated up to +120 °C, and is manufactured according to DIN 46228 Part 4 specifications. The ferrule has an insulation diameter of 2.5 mm maximum and dimensions of 15.0 mm (A) × 8.0 mm (B) × 1.95 mm (C) × 5.4 mm (D) × 3.4 mm (E), with a 10.0 mm strip length. The color-coded insulation protects the crimped connection from contact, and the ferrule is crimped using AMP precision tools to ensure reliable electrical and mechanical connection. This product is ideal for automotive powertrain systems, safety and security systems, and other applications requiring secure termination of dual flexible leads in switching cabinets, control units, and equipment with row clamp or poke-in clamp connectors.

Product Highlights:

Tubular End Sleeve
Wire Range = (2) 1.00² [(2) 17] mm [AWG]
Double Wire
Strip Length = 10.00 mm
Color = Red

Potential Applications:

Search Keywords: 9661444

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

966144-4

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
