91536-1

TE Connectivity / AMP Brand

Crimp Tool - Mini-Universal Mate-N-Lok Contacts - Te Connectivity / Amp 915. ...

Datasheet

RoHS Non-Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 91536-1 is a CERTI-CRIMP II straight action Hand Tool for use with Mini-Universal Mate-N-Lok contacts. The tool features a fixed die (crimper), a movable die (anvil), a locator/insulation stop and a ratchet. The insulation adjustment knob is used to regulate the crimp height of the contact insulation barrel during the crimping operation. The locator/insulation stop positions the contact and limits the insertion distance of the stripped wire into the contact. In use, the locator/insulation stop rests in the locator slot of the contact. The ratchet assures full crimping of the contact. Once engaged, the ratchet will not release until the dies have been fully closed.

Product Highlights:

Potential Applications:

Search Keywords: 915361

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

91536-1

RoHS:

HTS:

8205598000

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
