9-146257-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

9-146257-0

80 MODII HDR DRST B/A .100CL LF ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

9-146257-0 is a double row vertical breakaway header with solder tails, part of the AMPMODU .025 [0.64] square interconnection system. This header features 80 positions with .100 [2.54] centerline spacing and dimensions of A = 3.984 [101.19] inches/mm and B = 3.900 [99.06] inches/mm. The header has C = .120 [3.05], D = .230 [5.84], and E = .185 [4.70] dimensions with 30 Au Duplex plating option. It can be broken to desired number of positions using Tool Kit No. 314816-1. This RoHS compliant header is suitable for board-to-board interconnection applications requiring reliable vertical mounting configurations.

Product Highlights:

  • Header
  • Header Type = Breakaway
  • Number of Rows = Dual
  • Number of Positions = 80
  • Mating Post Length = 5.84 mm

Search Keywords: 91462570

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
9-146257-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Package Type:
BOX
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
80
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 9-146257-0 RoHS compliant?

Yes, 9-146257-0 is RoHS compliant.

What is the lead time for 9-146257-0?

The standard lead time for 9-146257-0 is approximately 18 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 5,276

Can Ship immediately

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 50

Multiple: 50

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
50
$28.23
250
$28.16
500
$28.10
750
$28.03
1,500
$14.31
2,250
$9.74
3,000 +
$9.55
