819959-SF
TE Connectivity / AMP BrandIEC Inlet HP Filter with Dual Fuse 250VAC 10A < ...
DESCRIPTION
The 819959-SF is an IEC inlet filter module (FN 9262 series) designed as a high-performance power entry module with integrated dual fuse holder for EMI/RFI suppression. It operates at 250 VAC, 50/60 Hz with rated currents from 1 to 10 A at 40°C maximum, and supports operating frequencies from DC to 400 Hz. The module features selectable design variants including standard, safety (A type), and medical (B type) versions, with high potential test voltages of 2000–2500 VAC depending on type, and complies with IEC/EN 60601-1 and UL 60939-3 standards. Key electrical characteristics include leakage currents of 0.31 mA (standard) or 0.07 mA (safety/medical types) at 250 VAC/50 Hz, inductance values ranging from 1.15 to 40 mH, and capacitance elements (Cx: 0.22 µF, Cy: 0.47–2.2 nF) for effective noise filtering. The module operates reliably across a temperature range of -25°C to +85°C and is housed in a compact design with optional snap-in mounting, making it suitable for industrial power supplies, medical equipment, and consumer electronics requiring robust EMI filtering and safety compliance.
Search Keywords: 819959SF
SPECIFICATIONS
IN STOCK: 80
Can Ship immediately
MOQ for In Stock Qty: 4
MOQ for out of Stock Qty: 4
Factory Lead-Time 13 Weeks
Datasheet
