770985-1 by te connectivity / amp brand
Image is representational - see mfr. specs

770985-1

TE Connectivity / AMP Brand

MINI UMNL PIN 26-22AWG SN LP ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 770985-1 is a miniature UMNL pin designed for wire gauges ranging from 26 to 22AWG. This pin features a tin plating for increased durability and conductivity. It is a reliable and versatile component for your electrical connections, suitable for various applications.

Product Highlights:

  • Contact
  • Mini-Universal MATE-N-LOK
  • Pin
  • Loose Piece
  • Wire Range = 0.12-0.40² [26-22] mm [AWG]

Search Keywords: 7709851

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
770985-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Power
Gender:
Pin
Contact Size:
N/A
Wire Size:
22-26 AWG
Contact Material:
Brass
Contact Plating:
Pre-Tin
Maximum Current Rating:
9.5 A
Termination Method:
Crimp
  Different packaging options available.  See Alternatives

IN STOCK: 53,500

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 21 Weeks

Qty
Unit Price
1,000
$0.0960
3,000
$0.0918
5,000
$0.0913
8,000
$0.0885
25,000
$0.0860
50,000
$0.0856
100,000
$0.0851
150,000 +
$0.0847
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

172164-1

Connector Housing - Mini Universal MATE-N-LOK Series - Plug - 1 Ways - 4.14 mm.

172335-1

MINI UMNL PLUG HOUSING 1P

1-172164-2

MINI UNIVERSAL M-N-L PLUG 1P

172156-1

1 CIR UNIV M-N-L CAP

1-172156-2

1 POS SR MINI UNIV

455830-1

Insertion Tool for Universal MATE-N-LOK; Commercial MATE-N-LOK; Mini-Universal MATE-N-LOK

189727-1

Extraction Tool for Mini-Universal MATE-N-LOK

90758-2

PROCRIMP DIE MINI UNIV MNL

90758-1

PROCRIMP TL W/DIE MIN UNIV MNL

91529-1

Crimp Tool - Straight Action Hand Tool - 26AWG-22AWG - Hand - MATE-N-LOK Series - CERTICRI ...

1-172165-2

The 1-172165-2 is a 2-circuit plug housing from the Mini-Universal MATE-N-LOK connector se ...

172165-1

This 2 circuit plug from TE’s Mini-Universal MATE-N-LOK Connectors series can be used for ...

172327-1

UNIV M-N-L HSG

Show 11 More
