62613-2

Name: 62613-2 Te Connectivity Amp Brand Ring Lug
Brand: Te Connectivity Amp Brand
SKU: 10457326
Availability: InStock

RING .190 12-10 AWG 0245 TPCRS ...

View Datasheet

RoHS Compliant

REEL Packaging

Certificate of Compliance

DESCRIPTION

62613-2 is a machine-applied open barrel ring tongue terminal designed for electrical connections in medium-gauge wire applications. It accommodates wire sizes 12-10 AWG (3.0-6.0 mm²) and features a 1/4" (6.35 mm) stud hole diameter for secure fastening to terminal studs. The terminal is constructed from tin-plated copper material with a stock thickness of 0.024 inches (0.61 mm), providing excellent corrosion resistance and electrical conductivity. Dimensional specifications include a width of 11.94 mm, length of 25.57 mm, and height of 19.56 mm with a contact depth of 8.64 mm. This terminal is commonly used in automotive wiring harnesses, industrial control panels, and power distribution systems where reliable mechanical and electrical connections are required.

Product Highlights:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Barrel Type = Open Barrel
Wire/Cable Type = Regular Wire
Wire Range = 3.00-6.00² [12-10] mm [AWG]

Potential Applications:

Search Keywords: 626132

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

62613-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
